This Web page has some info about and items for HeathKit and Heath - Zenith Z-100 series computers, which were built and sold in the 1980's. The Z-110 model pictured on the left is generally called the low profile model, without an internal CRT monitor; the Z-120 or "all-in-one" model had a internal monochrome CRT monitor (which many updated to color). Brief specifications of the Z-100 series is: a S-100 or IEEE-696 standard motherboard backplane but with on-board dual processor (8088 and 8085) and memory (256K or 768Kbytes), and "daughterboard" video (32K or 64K of RGB color or monochrome). S-100 cards from Heath included a floppy disk controller, additional memory, a hard drive controller, 4-port serial card. Many other S-100 companies offered add on cards. These systems were bought by the US military for training, and a number of universities bought them or required them for students. These are very reliable and rugged systems; many are still in use to this day (2003), and some still appear at military surplus auctions. A Zenith external 8-inch floppy drive system in pictured in my disk drive section
This page is pretty busy: I have here the following:
Ordering information and how to email @ me can be found in this notice.
Moved to another page with details on the Z-100 system and its history.
We are always looking for selected Z-110 and Z-120
items at VERY MODEST PRICES, for other people interested in these systems. That price also
also means COSTS OF SHIPPING if you ship, so I need to know your CITY/STATE/ZIP.
If you want me to PICK UP YOUR STUFF I also need your CITY/STATE/ZIP so I can decide if I
can drive that distance (from central New Jersey). I also need a GENERAL DESCRIPTION and
some CLUE ABOUT SIZE (volume, weight) of what you have. And I need to know WHEN YOU WANT TO MOVE
THE STUFF. ***PLEASE TELL ME THESE THINGS UP FRONT***, it will save time and fuss.
Typically (since say 2005), we obtain these from people who want to see their systems and stuff "go to good
homes" rather than be discarded. Space and budget limit what I can buy or even take for free; our priorities
are to obtain manuals and diskettes, 8-inch drives and cabinets, some S-100 cards. Whole systems
are difficult to ship or to pick up. And I can't just drive across country at a moment's notice.
But we may now of OTHER PEOPLE who want systems who can stop by.
This is my policy for 2006.Contact me if you WANT a system, or contact me if you HAVE a system or parts to offer. But give me ALL THE INFO YOU CAN so I can be clear as to what I can do. However if, as it often happens, you
email me to offer a lot of stuff and then say "I live (somewhere far away) and I have to get rid of my
stuff in a week, come get it", chances are I can't do that. Sorry. Maybe I can refer you to someone else,
that's about it. In 2006 we don't have complete "low profile" Z-100 systems ready for sale.
I don't have time to prepare them currently. These would have either 768K
of memory or 192K of memory, a floppy controller and one 360K floppy drive,
and 32K or 64K of video memory. In general these will be tested and working
when shipped, but some may require mechanical work on cases, floppy drives, etc.
Minimum shipping weight is about 50 lbs. We will not ship the "all in one"
systems with internal CRT monitor, they are too heavy and too easily damaged.
Other Heath Zenith Z-100 cards: prices do not include shipping or additional testing, ask about testing costs. These boards were tested several years ago unless noted otherwise. Winchester (hard disk drive) card sets are sometimes available, if
you have a set I'd be interested in them. When I have them, they will
include cables and software, but hardware and bracket to mount the
data seperator card and hard drive are offered seperately.
Zenith Z207-41 8-inch floppy drive enclosures and 8-inch drives are mentioned in the
drives section of my WEb page. The 30 page manual is available
as a copy from me, ask for details.
The Z-100 series had two models of power supplies. Zenith docs list some of them as follows. The Winchester drive" model has a P6 connector for the drive controller.
Low profile model- 234-200 I have a few of these pulled from working systems. I think the low profle model with P6 connector is rectangular shaped and has the Zenith number ZDS-234-432. The "all in one" model with the CRT had a power supply shaped like a small box with a wedge-shaped top, number ZDS-234-431. I'd sell a good used one for $29 plus shipping, shipping weight 10 lbs. Let me know if you must have the P6 connector for a Zenith Winchester controller.
Manuals for hardware are listed with the manual sets
below.
We have originals manuals and disks for sale for Z-100 and other
Heath/Zenith computers. We may provide copies
of manuals but not copies of some software, ask. Prices will vary with supply
and interest, ask for more info on specific
packages. Page counts are approximate, weights for shipping purposes.
"Half-sized" means manuals are 8.5 inch by 5 inch, otherwise manuals
and binders are for 8.5 by 11-inch pages. Manuals and disks are believed
to be complete and in good condition but are sold AS IS. Copies are generally
priced by the page and are made on commercial quality photocopiers. I have
had few complaints to date on previous sales, but know what you are buying
and ask me if you wish me to check disks for version numbers.
Note: MS-DOS version 1.25 is considered "collectable" and will command
a much higher price from collectors. We will have to determine current value before
offering it. Similar considerations may apply to early versions of other older software.
These are Zenith's early PC compatible systems. Please don't ask me if I want or will buy these systems, they just are not of great interest to me. I only have a few manuals, the manuals are for sale as listed below.
I'm very fond of these systems, I used these some years ago and worked with a developer
and manufacturer of H89 cards. I have a few of these systems, but I don't have time
these days to do much with them.
Thanks to the generousity of a Boston area H-8 owner, I acquired an H-8 in 2005. I'm desperate for time to set it up and show it off, and to work with it. I'm interested in acquiring additional H8 cards for it. Of course I also want to offer good copies of the H8 manuals I've acquired, some of which are listed below.
The H8 is an interesting machine in many respects. It has an OCTAL display and keyboard, not a binary front panel like other 8080 machines. The motherboard is SIDE mounted, not on the bottom, and uses a pin and socket connector and not an edge connector. (The h89 used similar connectors for their I/O cards.) A shorter-length bus than the S-100 means it can run a little faster, some people have souped up their H8's to several Megahertz.
And there are Z80 and other upgrade cards which were built for this system. But the original used a cassette board and tape storage, like the early H89.
If you have an H8 and a Web site, I'll consider adding a link here to your site. If you have H8 stuff to offer, let me know. For instance, I got in touch with Les Bird in June 2009: he's got some new H8 cards! Follow this link for details.
H8 manuals: 2007 acquisition. ask for quote for copies.
595-2014-02 H8 Operation Manual As of 2009, here is what I have in my archives. Let me know if
you are interested in a duplicate issue or a photocopy, or a copy of an
article (but you determine which issues!), I'll set a price accordingly.
As of Sept 2003 an index of Sextant articles
can
be found via this link to the Z-100 Lifeline magazine site.
An index
of REMark issues is on this Web page.
Another Web site has
photos and an index of REMark magazines. REMark ended in June 1992.
Some of my magazines are from Col. Williams'
collection; some were donated courtesy of the Langstons. Thank you.
Most of these Heathkit manuals are in good condition, ask for specifics. We'll price
these at $10 each plus shipping; I may negotiate lower for smaller manuals. I'll consider making copies of
these manuals but the copies will still be several dollars each depending on page count.
Note: I may have additional manuals with some instruments, check my
odds and ends page for details.
Many of these manuals and the magazines above
were provided in memory of Col. Robert D. Williams, USAF, by
his wife. Col. Williams built and used many of these Heathkit items. His wife told me
"..if some of these manuals get passed on, people will know that
once there were people who could actually do things with their hands". After years of
working on Heathkits, Col. Williams turned to computer art and created fractal images:
samples of his work can be found on his site.
There are many Web pages about the "old" Heath and old Heathkits, a Web
search will find them. Most are about the Heath ham radio kits or other kits,
a few are devoted to Heath and/or Zenith computers. I have afew Web links sprinkled through this Web document, but here are more. For the larger world of CP/M and S-100 Web pages, check my Web links page for S-100.
"Z-100 LifeLine" former magazine Web Site In a 2009 private email, Les Bird of the Society of Eight-Bit Heathkit Computerists (SEBHC) archive site alerted me to this organization and this Web archive. There is also a SEBHC Google group. He said: "I have several H-8 computers and H89 computers and a website that is, for now, the home of the SEBHC archive. In addition to many disk images and ROM dumps available on my website I also have several newly designed PCBs for the H8 computer that I offer to those who are interested." The boards are priced near cost plus shipping. The Google group dates from late 2007 and (for a old computer discussion group) is modestly active.
I obtained a board set from Les in June 2009. Many thanks!
Here's an image of Les Bird's Z80 H8 cpu board, with his ROM.
Note: you may have found this Web page while looking for information
on Heath/Zenith products purchased in year 2002 or later. You should
know that the original "Heath", the old computer and hobby electronic kit company
(which is featured on this Web site) from Benton Harbor MI was liquidated in the mid 1990's. The
"Heath/Zenith" trade mark and name was sold seperately.
One apparently licensed user of the "Heath/Zenith" name markets various
home electronic products. It happens I got something from "Heath/Zenith" in 2002 at Home Depot (a USA national hardware superstore).
The bottom of its packing box says "DESA International, Bowling Green KY 42102,
Manufactured in China". A Web page at http://www.desaint.com/
refers to several product lines including "Heath/Zenith".
In 2008 I was alerted that Duchossois Industries includes the Heath/Zenith name and may have registered "heath-zenith.com". Their site says one of their "portfolio companies" is "heath-zenith" which links to the DESA Customer Care center. Check their sites for more information. If you want more info about
RECENT Heath Zenith home products, I suggest you check that site, or
read the lables on the box, or contact the store you bought your product from. One of these may refer you to the manufacturer;
or the store may have additional info on the product or the manufacturer. I have
no information on products from Desa International.
Another apparent licenser of the "Heath" name is Heathkit Company Inc.
or Heathkit Educational System, of Benton Harbor MI. All I know about this
company is from the information listed on their Web site at
heathkit.com. Their home page says "preparing
people for success in technology for over 75 years." This company appears to
provide educational trainers and training support for formal learning about
electronics of various sorts. They apparently support some of the old Heath Educational
materials and training manuals. They have links on their "support" Web page
to Desa International (mentioned above), and a link for old
Heathkit manual photocopies. (They no longer reference Hero support.)
The heathkit.com Web link for manuals as of 2009 is the "Professionals Heathkit Page" of Don Peterson.
Don has a small business of providing copies of manuals, and some odd parts and a "boneyard" of machines. He was a design engineer for Heathkit in the mid-1970's. Their Web page claims:
"Data Professionals of Pleasanton California has purchased the Copyrights and existing inventory of all legacy Heathkit product documentation from Heath Company of Benton Harbor Michigan for an undisclosed amount." Some discussion of this purchase and debate over what is covered, is on this Amateur Radio discussion forum. The title of the post is "DataPro purchases Heath Legacy Manual Service". Apparently the purchase was completed on OCtober 30 2008; apparently there is some contention over whether a copyright was transferred in the purchase, and the role of the US Copyright Office in that regard.
There are two other sites who use the Heath name with permission. Robert Doerr bought the Heath "Hero" robot name
and all the leftover parts, and offers support and info
via his Web site.
And, the Heathkit virtual museum is referenced on the Heathkit site,
at http://www.heathkit-museum.com/.
That site said they had permission to use the Heathkit name and links back to
"heathkit.com."
Electronic Design magazine's Web site has
an article by Louis E. Frenzel for Feb 2009 titled "Whatever Happened to Heathkit?". It's a good read but lacks some of the
updated information on this page as to where the "Heath" name has been sold or used recently.
If you have any corrections
to the above information I'd appreciate hearing
them: please include appropriate references so I can confirm that info. I am not
responsible for errors or omissions in the above info, use it at your own risk.
Herb Johnson
Copyright © 2009 Herb JohnsonH-100 systems wanted, for sale - PLEASE READ BELOW BEFORE YOU CONTACT ME
